Specifications
MECHANICAL
Dimensions (LxWxH)
105 mm x 102 mm x 150 mm (4.1 in x 4.0 in x 5.9 in)
Weight
400 g (14.1 oz)
ELECTRICAL
Input Voltage
5 VDC ± 0.25 V
Operating Power
900 mW (180 mA @ 5 V)
Standby Power
850 mW (170mA @ 5 V)
Host System Interfaces
USB, RS232, Keyboard Wedge, IBM 468xx (RS485)
ENVIRONMENTAL
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-40°C to 60°C (-40°F to 140°F)
Humidity
5% to 95% relative humidity, non-condensing
Drop
Designed to withstand 1.2 m (4 ft) drops
Environmental Sealing
Sealed to resist airborne particulate contaminants
Light Levels
4842 Lux
SCAN PERFORMANCE
Scan Pattern
Omnidirectional: 5 fields of 4 parallel lines; button activated single line (7180)
Scan Speed
Omnidirectional: 1120 scan lines per second; single line: 56 scan lines per second (7180)
Print Contrast
35% minimum reflectance difference
Pitch, Skew
60°, 60°
Decode Capability
Reads standard 1D and GS1 DataBar symbologies
Warranty
3 year factory warranty
