Epson LQ-2190 Dot Matrix Printer

SKU 8160 HSN:8443
रु 39,750
In stock
1
Product Details
PRINTER TYPEImpact Dot Matrix
Product NameEpson LQ-2190
Product CodeC11CA92011
Number of Pins in Head24 pins
Print DirectionBi-directional with logic seeking
Control CodeESC/P2 and IBM PPDS emulation
PRINT SPEED
High speed draft 10 cpi480 cps
High speed draft 12cpi576 cps
Draft 10 cpi360 cps
Draft 12 cpi432 cps
Draft 15 cpi540 cps
Draft 17 cpi (condensed)308 cps
Draft 20 cpi (condensed)360 cps
LQ 10 cpi120 cps
LQ 12 cpi144 cps
LQ 15 cpi180 cps
LQ 17 cpi condensed180 cps
LQ 20 cpi condensed240 cps
cpi : characters per 25.4 mm (characters per inch)
cps : characters per second
PRINT CHARACTERISTICS
Character sets14 international character sets and one legal character sets.
1 Italic and 12 graphical character tables
Italic table, PC437 (US Standard Europe), PC850 (Multilingual), PC860
(Portuguese), PC861 (Icelandic), PC863 (Canadian-French), PC865
(Nordic), BRASCII, Abicomp, Roman 8, ISO Latin 1, PC 858, ISO 8859-15
Fonts
Bitmap FontsEpson Draft 10, 12, 15cpi
Epson Roman 10, 12, 15 cpi proportional
Epson Sans Serif 10, 12, 15 cpi, proportional
Epson Courier 10, 12, 15 cpi
Epson Prestige 10, 12 cpi
Epson Script 10 cpi
Epson Script C Proportional
Epson OCR-B 10 CPI
Epson Orator 10 cpi
Epson Orator-S 10 cpi
Scalable FontsEpson Roman 8 to 32 points
Epson Sans Serif 8 to 32 points
Epson Roman T 8 to 32 points
Epson Sans Serif H 8 to 32 points
Bar Code FontEAN-13, EAN-8, Interleaved 2 of 5, UPC-A UPC-E, Code 39, Code 128, POSTNET
Coda bar(NW-7), Industrial2 of 5, Matrix2 of 5

cpi : characters per 25.4 mm (characters per inch)
PRINTABLE COLUMNS
Characters per line10cpi 136 cpl
12cpi 163 cpl
15cpi 204 cpl
17cpi condensed 233 cpl
20cpi condensed 272 cpl

cpi : characters per 25.4 mm (characters per inch),
cpl : characters per line
PAPER HANDLING
StandardManual Insertion (Front or rear in, top out),
Push Tractor (Front or rear in, top out),
Pull Tractor (Front or rear or bottom in, top out)
PAPER MEDIA
Cut Sheet (Single sheet)
Entry : Front
Width
Length
Thickness


100 - 420 mm (3.9 - 16.5 inch)
148 - 420 mm (5.8 - 16.5 inch)
0.065 - 0.14 mm (0.0025 - 0.0055 inch)
Entry : Rear
Width
Length
Thickness

100 - 420 mm (3.9 - 16.5 inch)
100 - 420 mm (3.9 - 16.5 inch)
0.065 - 0.14 mm (0.0025 - 0.0055 inch)
Cut Sheet (Multi part)
Entry : Front
Width
Length
Copies
Thickness


100 - 420 mm (3.9 - 16.5 inch)
148 - 420 mm (5.8 - 16.5 inch)
1 original + 5 copies
0.12 - 0.46 mm (0.0047 - 0.018 inch)
Entry : Rear
Width
Length
Copies
Thickness

100 - 420 mm (3.9 - 16.5 inch)
100 - 420 mm (3.9 - 16.5 inch)
1 original + 5 copies
0.12 - 0.46 mm (0.0047 - 0.018 inch)
Continuous paper (Single sheet and Multi part)
Entry : Front, Rear, Bottom
Width
Length
Copies
Thickness



101.6 - 406.4 mm (4 - 16 inch)
101.6 - 558.8 mm (4 - 22 inch)
1 original + 5 copies
0.065 - 0.46 mm (0.0025 - 0.018 inch)
Roll Paper
Entry : Rear
Width
Length
Diameter
Thickness


216 mm (8.5 inch)
-
127 mm (5 inch)
0.07 - 0.09 mm (0.0028 - 0.035 inch)
Envelope (NO.6)
Entry : Rear
Width
Length
Thickness


165 mm (6.5 inch)
92 mm (3.6 inch)
0.16 - 0.52 mm (0.0063 - 0.020 inch)
Envelope (NO.10)
Entry : Rear
Width
Length
Thickness


241 mm (9.5 inch)
105 mm (4.1 inch)
0.16 - 0.52 mm (0.0063 - 0.020 inch)
Label
Entry : Bottom
Base Sheet Width
Base Sheet Length
Total Thickness


101.6 - 406.4 mm (4 - 16 inch)
101.6 - 558.8 mm (4 - 22 inch)
0.16 - 0.19 mm (0.0063 - 0.0075 inch)
Card
Entry : Front, Rear
Width
Length
Thickness


100 - 200 mm (3.9 - 7.8 inch)
148 - 200 mm (5.8 - 7.8 inch)
0.22 mm (0.0087 inch)
Line Spacing4.23 mm (1/6 inch) or programmable in increments of 0.0706 mm (1/360 inch)
INTERFACE
StandardBi-directional parallel interface (IEEE-1284 nibble mode supported), USB 2.0 (Full Speed), Type B I/F level 2 (Option)
INPUT DATA BUFFER128 KB
RIBBON CARTRIDGE
ColourBlack
TypeFabric Ribbon Cartridge
Ribbon lifeApprox.15 million characters
RELIABILITY
Mean Print Volume Between Failure40 million lines (except print head)
Mean Time Between Failure20,000 Power on Hours (25% duty cycle)
Print Head Life400 million strokes/wire
CONTROL PANEL
6 switches and 10 LEDs are located on the panel
ENVIRONMENTAL CONDITIONS (operating)
Temperature5° to 35° C
Humidity10 to 80% RH
ELECTRICAL SPECIFICATIONS
Rated Voltage220V~240V
Rated frequency50 to 60 Hz
Power consumption


Energy Star Compliant
46W (ISO 10561 Letter pattern)
Approx. 3 W in sleep mode
0 W in powered off mode
DIMENSIONS
Width639 mm
Depth402 mm
Height256 mm
WeightApprox. 13 kg
Acoustic Noise54 dB
PRINTER DRIVER / UTILITY
Operating System
EPSON Status Monitor 3
EPSON Printer Setting
Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®
Microsoft® Windows®2000 / XP / 7, Microsoft® Windows Vista®
Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®
Standard Warranty12 months return to base)
OptionalAdditional 2 years return to base warranty - 3YWLQ2190
