Epson LQ-2090II Dot Matrix Printer

Call or WhatsApp us if you have any questions.

UPC: 010343850064

Brand: Epson

Product: New

Generic Name: Dot Matrix Printer

Model no.: LQ-2090II

Warranty: Epson India

Volumetric Weight: 18 kg

Epson LQ-2090II Dot Matrix Printer

Wide-format impact printers built for demanding print environments

Fast 24-pin, 136-column dot matrix printer that offers outstanding reliability and an extremely low total cost of ownership (TCO).

- Fast print speed: USD speed of 550 characters/second at 10 characters per inch
- Increased reliability: Mean time between failure of 25,000 power-on hours
- Flexible printing: 24-pin, 136-column dot matrix printer
- Increased number of copies: Now original plus six copies
- Same consumables: Uses the same ribbons as existing models

Fast print speed

The LQ-2090II offers an improved USD (ultra speed draft) speed of 550 characters per second at 10 characters per inch, making a real difference to high-volume print runs such as stock reports and large batches of invoices or freight documents.

Increased reliability

Epson's dot matrix technology is already mature and very reliable. Building on this, the new printer improves the mean time between failure by 25% to 25,000 power-on hours, ideal for challenging conditions or where regular maintenance is not practical.

Same consumables

This printer uses the same ribbons as existing models, so you can upgrade your hardware and continue to use your current ribbon supplies.

What's In The Box:

LQ-2090II Impact Printer
Printer driver disk
Quick Installation Guide
Rear sheet guide
Power cable
Push tractor unit
Ribbon catridge - black
Warranty certificate

Printing Technology:

Printer Type:24-pin, serial impact dot matrixPrint Method:Impact dot matrixPrinter Language:Epson ESC / P2, IBM PPDSControl Panel:6 switches and 10 LEDsPrint Direction:Bidirectional logic seeking for text and graphics printing; unidirectional text or graphics printing can be selected using software commandsColour:White/BlackNumber of Pins in Head:24 pins

Reliability:

Total Print Volume:50 million lines (not including printhead)MTBF:25,000 POH (25% duty cycle)Printhead Life:400 million characters, Draft 10 cpi, 14 dots/characterRibbon life:8 million characters, LQ 10 cpi, 48 dots/character2

Print Characteristics:

Character Sets:13 character tables
14 international countries character setsBitmap Fonts:Ultra High Draft: 10 cpi
High Speed Draft: 10, 12 cpi
Draft: 10, 12, 15, 17, 20 cpi
LQ: 10, 12, 15, 17, 20 cpiScalable Fonts:EPSON Sans Serif: 10.5 pt., 8 pt. - 32 pt. (every 2 pt.)Barcode:EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, POSTNET, Codabar (NW-7), Industrial 2 of 5, Matrix 2 of 5

Paper Path:

Manual Insertion:Front or rear in, top outPush Tractor:Front/Rear insertion, top outPull Tractor:Front/Rear/Bottom InsertionCut Sheet Feeder:Front/Rear Insertion

Paper Media:

Cut Sheet (Single Sheet):Width: 100-420mm (3.9" -16.5")
Length: 100-420mm (3.9" -16.5")
Paper Thickness: 0.065 - 0.14 mm (0.0025" - 0.0055")Cut Sheet (Multi-part Forms):Width: 101-406mm (4.0" - 16.0")
Length: 101-559mm (4.0" - 22")Cut Sheet (Multi-part Sheet):Paper Thickness: 0.12 - 0.39 mm (0.0047" - 0.015")Envelopes:No.6, No.10Continuous Paper (Single Sheet):Width Continuous:Continuous Paper (Multi-part Forms):Forms, continuous, multipart (original + 5 carbonless copies), 1 + 6 copies with Pull Tractor (optional), labels, and roll paper Maximum Thickness 0.14 mmRoll Paper:216mm

Environmental Conditions (Operating):

Temperature:5 - 35°CHumidty:10 - 80%Electrical Specification:Operating Mode: Approx. 52 W (ISO/IEC 10561 Letter Pattern) Ready Mode: Approx. 12 W Sleep Mode: Approx. 0.5 W and 0.8 W (Network Model) ENERGY STAR Compliant: Certified with V2.0Rated Voltage:240 VRated Frequency:50 Hz

Acoustic Noise:

Acoustic Noise:55 dBA (ISO 7779 pattern)

Input Data Buffer:

Input Data Buffer:128 KByte
