FEATURES
CODE CAPABILITY
UPTO 1 – 4
200 MILLION CHARACTERS FOR PRINT HEAD 10 MILLION CHARACTERS FOR INK BANK
15,000 POWER-ON
HOURS – HIGHER RELIABILITY
SILICON SELF-LUBRICATION- MAINTENANCE FREE
FASTER PRINTING
SPEED – 450 CPS
SPECIFICATIONS
Print Method
Serial Impact Dot Matrix
Print Direction
Bi directional Logic seeking
Print Head
Type 9 Wire
Print Width
80 Column
Print Head Life
200 million characters
Character Pitch cpi
10 12 15
High Speed Draft cps
333 – 338
Draft cps
300 250
Near letter quality cps
High Speed Draft
Draft
Standard 10, 12, 15, 17 and 20 cpi
Near Letter Quality
Roman, Sans Serif, Script
Resident bar code
Code 3 of 9
Paper path standard
Top, Rear and Bottom
Continuous Tractor feed standard
Convertible push & Pull
Continuous form width
3.5 – 10 “
Cut sheets width
3.5 – 10 “
Paper thickness max
Tractor feed 0.3mm
Friction feed 0.3mm
Copy capability
Type
Patented TVS ribbon cassette with user
Colour
Jet black
Ribbon Life
40 Million characters with 3 additional inkbanks
Cassette refill mode
Through Inkbank
Inkbank life
10 Million Characters
Input Buffer Kilo bytes
100 KB
Reliability MTBF Power on Hours
15,000 POH
Acoustics Noise level
Emulation
ESC/P
Standard Interface
Centeronics IEEE/P1284A Parallel , USB 2.0
Optional Interface
RS 232C Serial
Operating voltage
150 – 270V AC
Mains frequency
47 – 63 Hz
Power Standby
12W
Temperature
+5 to + 45ºC
Relative Humidity
10% to 80%
Size W x D x Hmm
433 x 379 x 147
Weight
5.7 kg
Warranty
2 Years incl. Print head (only valid on registration)
Best Suited for Printing
