Unrivalled Performance
MCBF of 60 million lines and an auto-cutter life of 1.5 million cuts.
Ease-of-use
The TM-T82X features drop-in paper loading, auto cutter and status LEDs.
Adaptive Design
Space saving compact design makes it easy to suit even the most demanding retail environment.
General Information:
Power Specifications:Built-in power supplyProduct Power Consumption:Power Consumption: Operating: Approx. 27.8 W Standby: Approx. 0.96 W
Supply Voltage: AC 100 to 230V / 50 to 60 Hz
Option:
External Buzzer:External buzzer unit
Print Font:
Font:9 × 17 / 12 × 24, Hanji Font: 24 x 24, Thai Font: 9 x 24 / 12 x 24Characters Per Inch:22.6cpi / 16.9cpi, Hanji Font: 7.8cpi, Thai Font: 22.6cpi / 16.9cpiCharacter Size (W x H):0.88 × 2.13 mm / 1.25 × 3 mm, Hanji font: 3 x 3 mm, Thai font: 0.88 x 3 mm / 1.25 x 3 mmCharacter Set:95 Alphanumeric, 18 set International, 128 × 43 pages (including Thai / Viet and user-defined page) Hanzi: Simplified Chinese: GB18030-2000: 28,553 Bar code: UPC-A, UPC-E, JAN13(EAN13), JAN8(EAN), CODE39, ITF, CODABAR(NW-7), CODE93, CODE128, GS1-128, GS1 DataBar Two-dimensional code: PDF417, QRCode, MaxiCode, 2D GS1 DataBar, Composite Symbology
Data Buffer:
Data Buffer:4KB or 45bytes
Print Speed:
Print Speed:Max 200mm/s
Paper:
Width and Roll Diameter:79.5 ± 0.5mm
Overall Dimensions (D x W x H):
Overall Dimensions (D x W x H):192 x 149 x 140 mm
Printing Method:
Printing Method:Thermal Line Printing
Standard Accessories:
Standard Accessories ROM:Roll paper × 1 roll (for checking the initial movement of the printer), Setup guide, USB cable for USB + Serial model
Dot Density:
Dot Density:203 x 203 dpi
Mass:
Mass:Approx. 1.5kg
Interfaces:
USB:YesSerial:YesInterfaces:Built-in USB + Serial (9pin)
Reliability:
MTBF:360,000 hoursMCBF:60,000,000 linesPrinter Mechanism Life:15 million linesAuto Cutter Life:1.5 million cuts
Printer Details:
Other Features:Built-in: Automatic Paper Reduction, Automatic paper cut with logo printing
Supported OS and Applications:
Supported OS:Windows, Mac, Linux
Additional information
| Printer Type |
Thermal |
|---|---|
| Print Function |
Yes |
| Print Speed |
up to 200mm/sec |
| Print Resolution |
203dpi（8dot/mm） |
| Printing Width |
79.5 ± 0.5 mm |
| Cutter |
Auto Cutter, Manual Cutter |
| Control Panel |
Notification buttons |
| Onsite Installation Support |
Yes, on call charge basis |
| Additional Warranty Option |
No |
| Onsite Warranty |
Yes |
| OS Support |
Linux, Windows |
| Interface |
USB |
| WiFi Direct |
No |
| Wireless |
No |
| Network (LAN) |
Optional |
| Mobile Printing |
No |
