Model Number: LS106P
Brand: TP-Link
Product Type: Unmanaged Desktop PoE+ Switch
Total Ports: 6 × 10/100 Mbps RJ45 Ports
PoE+ Ports: 4 × 10/100 Mbps RJ45 Ports (Ports 1–4)
Non-PoE Ports: 2 × 10/100 Mbps RJ45 Ports
PoE Standards: IEEE 802.3af/at
Maximum PoE Output per Port: Up to 30 W
Total PoE Power Budget: 65 W
Switching Capacity: 1.2 Gbps
Packet Forwarding Rate: 0.893 Mpps
MAC Address Table: 2K
Jumbo Frame: 2 KB
Transmission Method: Store-and-Forward
Extend Mode: Supported (Up to 250 m on Ports 1–4)
Isolation Mode: Supported
PoE Auto Recovery: Supported
Auto-Negotiation: Supported
Auto MDI/MDIX: Supported
Network Cable: Cat 3, Cat 4, Cat 5, or higher as applicable
Maximum Standard Transmission Distance: 100 m
Power Supply: External Power Adapter
Power Adapter Output: 53.5 V DC / 1.31 A
Maximum Power Consumption: 66.53 W
Cooling: Fanless Design
Installation: Desktop / Wall-Mount
Dimensions (W × D × H): 99.8 × 98 × 25 mm
Operating Temperature: 0°C to 40°C
Storage Temperature: -40°C to 70°C
Operating Humidity: 10%–90% (Non-Condensing)
Storage Humidity: 5%–90% (Non-Condensing)
Certifications: CE, RoHS and other region-dependent certifications
Package Contents: Switch, Power Adapter, Rubber Feet, Installation Guide
