Features
Supercharge Your NAS
Boost your NAS system’s performance and responsiveness with the WD Red™ SA500 NAS SATA SSD. Since your NAS system is always on, a reliable drive is essential. Unlike standard SSDs, WD Red NAS SATA SSDs are specifically designed and tested for 24/7 usage. This durability together with efficient caching of big files make these drives ideal for OLTP databases, multi-user environments, photo rendering, 4k and 8k video editing and other demanding applications. With 2.5” form factors and 500GB capacity, the WD Red SA500 NAS SATA SSD lets you optimize your existing or next NAS system for superior performance and endurance.
Access Big Files Fast
WD Red™ SA500 NAS SATA SSD storage is optimized for caching in NAS systems to rapidly access your most frequently used content.
Give It Your Tough Workloads
WD Red™ SSD’s superior endurance can handle the heavy read and write loads demanded by NAS, giving you the reliability you need in a 24/7 environment.
Work More Efficiently
Purpose-built for NAS with proven Western Digital® 3D NAND, the WD Red™ SSD delivers maximum SATA performance to boost your productivity and effectiveness at home or in the office.
Use it for Your Demanding Applications
The drive reduces latency and improves responsiveness for OLTP databases, multi-user environments, photo rendering, 4K and 8K video editing, and more.
Customize Your NAS System
The WD Red™ SSD comes in 2.5” form factors so you can upgrade your existing NAS system or design a new one from scratch.
Specifications
| Form Factor | 2.5” |
| Interface | SATA III 6 Gb/s |
| Sequential Read up to (MB/s) | 560 |
| Sequential Write up to (MB/s) | 530 |
| Random Read up to (IOPS) | 95K |
| Random Write up to (IOPS) | 85K |
| Endurance (TBW) | 600 |
| Average Active Power (mW) | 60 |
| Max. Read Operating (mW) | 2,550 |
| Max. Write Operating (mW) | 3,750 |
| Slumber (mW) | 56 |
| DEVSLP (mW) | 5-12 |
| MTTF (M hours) | Up to 2M |
| Uber | 1E10^17 |
| Operating Temperatures | 0°C to 70°C |
| Non-Operating Temperatures | -55°C to 85°C |
| Operating Vibration | 5.0 gRMS, 10-2000 Hz |
| Non-Operating Vibration | 4.9 gRMS, 7-800 Hz |
| Shock | 1,500 G @ 0.5 msec half sine |
| Certifications | FCC, UL, TUV, KC, BSMI, VCCI |
| Size and Weight | 100.2mm x 69.85mm x 7.00mm @ 37.4g |
| Warranty | 5 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
- CAPACITY1TB
- SERIESRED SA500
- FORM FACTOR2.5 INCH
