300Mbps Universal Wi-Fi Range ExtenderTL-WA850RE

• Range Extender mode boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly
• Miniature size and wall-mounted design make it easy to deploy and move flexibly
• Easily expand wireless coverage at a push of Range Extender button
• Ethernet port allows the Extender to function as a wireless adapter to connect wired devices
• Tether App allows easy access and management using any mobile device
• LED Control function includes a Night Mode for peaceful sleep

• Easy Wi-Fi Extension
  Flexible Placement

  300Mbps Universal Wi-Fi
  Range Extender
  TL-WA850RE

• Boost Your Wireless Network

  Tired of Wi-Fi ’’dead zone’’? TP-LINK’s range extender connects to your router wirelessly, strengthening and expanding its signal into areas it can’t on its own. The device also reduces signal interference to ensure reliable Wi-Fi coverage throughout your home or office.

• Boost Your Wireless Network

  Tired of Wi-Fi ’’dead zone’’? TP-LINK’s range extender connects to your router wirelessly, strengthening and expanding its signal into areas it can’t on its own. The device also reduces signal interference to ensure reliable Wi-Fi coverage throughout your home or office.

• Ethernet Bridge

  The TL-WA850RE’s single Ethernet port allows the Extender to function as a wireless adapter to connect wired devices like Blu-ray® players, gaming consoles, DVRs and Internet TVs. At the same time, the device can share the wireless network as well.

• Smart Signal Indicator Light

  5 signal lights show the strength of signal that TL-WA850RE receives from the existing router, which can help to find the right location to place the range extender.It’s recommended that you choose a location where at least 3 signal light blue in order to guarantee a good performance.

• Smart Signal Indicator Light

  5 signal lights show the strength of signal that TL-WA850RE receives from the existing router, which can help to find the right location to place the range extender.It’s recommended that you choose a location where at least 3 signal light blue in order to guarantee a good performance.

• HARDWARE FEATURES
  Plug Type	EU, UK, US
  Interface	1 * 10/100M Ethernet Port (RJ45)
  Button	RE (Range Extender) Button, Reset Button
  Power Consumption	About 3W
  Antenna	2 * internal
  Wireless Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
  Dimensions ( W x D x H )	4.3x 2.6 x 3.0in. (110.0 x 65.8 x 75.2mm)

  WIRELESS FEATURES
  Frequency	2.4~2.4835GHz
  Signal Rate	11n: Up to 300Mbps (dynamic) 11g: Up to 54Mbps (dynamic) 11b: Up to 11Mbps (dynamic)
  Reception Sensitivity	270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER
  Transmit Power	< 20 dBm (EIRP)
  Wireless Modes	Range Extender
  Wireless Functions	WMM (Wi-Fi Multimedia) Wireless MAC Address Filtering Wireless Statistic Domain Login Function
  Wireless Security	64/128/152-bit WEP WPA-PSK / WPA2-PSK

  OTHERS
  Certification	CE, RoHS
  Package Contents	300Mbps Universal Wi-Fi Range Extender TL-WA850RE RJ-45 Ethernet Cable Resource CD Quick Installation Guide
  System Requirements	Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
  Environment	Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
