Canon E410 Color All in One Inkjet Printer
|Maximum Printing Resolution||4800 (horizontal)*1 x 600 (vertical) dpi|
|Print Head / Ink||Type||FINE Cartridge|
|Number of Nozzles||Total 1,280 nozzles
|Ink Cartridge||PG-47, CL-57S|
Based on ISO / IEC 24734.
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions
|Document: Colour:||ESAT / Simplex||Approx. 4.0ipm|
|Document: B/W:||ESAT / Simplex||Approx. 8.0ipm|
|Printable Width||Up to 203.2mm (8-inch)|
|Printable Area||Bordered Printing||Top margin: 3mm, Bottom margin: 16.7mm,
Left / Right margin: each 3.4mm
(Letter / Legal: Left: 6.4mm, Right: 6.3mm)
|Recommended Printing Area||Top margin: 31.6mm
Bottom margin: 29.2mm
|Paper Size||A4, A5, B5, Letter, Legal, 4 x 6", 5 x 7", Envelopes (DL, COM10), Custom size (width 101.6 - 215.9mm, length 152.4 - 676mm)|
|Plain Paper||A4, A5, B5, Letter = 60, Legal = 10|
|Photo Paper Plus Glossy II (PP-201)||4 x 6" = 20, 5 x 7" = 10|
|Glossy Photo Paper "Everyday Use" (GP-601)||4 x 6" = 20|
|Envelope||European DL / US Com. #10=5|
|Glossy Photo Paper (GP-508)||4 x 6" = 20|
|Canon Oce Red Label Paper (WOP111)||A4 = 60|
|Canon Oce Office Colour Paper (SAT213)||A4 = 50|
|Paper Weight||Rear Tray||Plain Paper: 64-105 g/m2, Canon specialty paper: max paper weight: approx. 275 g/m2(Photo Paper Plus Glossy II (PP-201))|
|Ink End Sensor||Dot count|
|Print Head Alignment||Manual|
|Scanning Method||CIS (Contact Image Sensor)|
|Optical Resolution*4||600 x 1200dpi|
|Selectable Resolution*5||25 - 19200dpi|
|Scanning Bit Depth (Input / Output)||Grayscale:||16bit / 8bit|
|Colour:||48bit / 24bit (RGB each 16bit / 8bit)|
|Line Scanning Speed*6||Grayscale:||1.2ms/line (300dpi)|
A4 Colour / 300dpi
|Maximum Document Size||Flatbed:||A4 / Letter (216 x 297mm)|
|Maximum Document Size||A4 / Letter (216 x 297mm)|
|Compatible Media||Size:||A4, Letter|
|Image Quality||Plain Paper: Draft, Standard|
|Copy Speed*8||Document: Colour||sFCOT / Simplex||Approx. 30secs.|
|sESAT / Simplex||Approx. 1.8ipm|
|Multiple Copy||Black / Colour||1 - 21 pages|
|System Requirements(Please visitwww.canon-asia.com to check OS compatibility and to download the latest driver updates.)||Windows:||
Windows 10, Windows 8, Windows 7 SP1, Windows Vista SP2
|Macintosh:||Mac OS X v10.8.5and later|
|Interface||USB B Port||Hi-Speed USB|
|Operating Environment*9||Temperature: 5 - 35°C
Humidity: 10 - 90% RH (no dew condensation)
|Recommended Environment *10||Temperature: 15 -30°C
Humidity: 10 - 80% RH (no dew condensation)
|Storage Environment||Temperature: 0 - 40°C
Humidity: 5 - 95% RH (no dew condensation)
|Acoustic Noise (PC Print)||Photo (4 x 6")*11||Approx. 46.0db(A)|
|Power||AC 100-240V 50 / 60Hz|
|Power Consumption||OFF:||Approx. 0.4W|
|Standby (scanning lamp is off):||Approx. 1.0W|
(Wireless LAN connection to PC)
|Environment||Regulation||RoHS (EU, China)*, WEEE (EU)*
*To be fixed
*To be fixed
|Dimension (W x D x H)||Approx. 426 x 306 x 145mm|
|Specifications are subject to change without notice.|
|*1||Ink droplets can be placed with a pitch of 1/4800 inch at minimum.|
|*2||Document print speeds are the averages of ESAT in Office Category Test for the default simplex mode, ISO / IEC 24734.
Photo print speed is based on the default setting using ISO / JIS-SCID N2 on Photo Paper Plus Glossy II and does not take into account data processing time on host computer.
Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
|*3||TWAIN driver (ScanGear) is based on the TWAIN specification V1.9 and requires the Data Source Manager comes with the operating system.|
|*4||Optical resolution is a measure of maximum hardware sampling resolution, based on ISO 14473 standard.|
|*5||Increasing the scanning resolution will limit the maximum possible scanning area.|
|*6||The fastest speed in Hi-Speed USB on Windows PC. Transfer time to computer is not included.|
|*7||Color document scan speed is measured with ISO / IEC 29183 Target A.
Scan speed indicates the time measured between pressing the scan button of the scanner driver and the on-screen status display turns off.
Scan speed may vary depending on system configuration, interface, software, scan mode settings and document size etc.
|*8||Copy speeds are the average of sFCOT and sESAT, ISO/IEC 29183.
Copy speed may vary depending on document complexity, copy mode, page coverage, type of paper used etc. and does not take into account warm-up time.
|*9||The performance of the printer may be reduced under certain temperature and humidity conditions.|
|*10||For the temperature and humidity conditions of papers such as photo paper, refer to the paper's packaging or the supplied instructions.|
|*11||When printing ISO / JIS-SCID N2 on 4 x 6" Photo Paper Plus Glossy II using default settings.|
|*12||Copy: When copying ISO/JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings.
Print: When printing ISO/JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings.
You need to install ink tanks or ink cartridges of all colours whether you perform black and white printing or colour printing. If any one of the ink tanks or ink cartridges is not installed, an error occurs and you cannot perform printing.
Depending on the paper or the print settings, colour ink may be consumed even when you print a document in black or perform printing in black and white. When any one of the colours of ink has run out, you need to replace the ink tank or ink cartridge.
When you use the Canon printer for the first time after you install the bundled ink tanks, the printer consumes a small amount of ink in the amount to enable printing by filling the nozzles of the Print Head with ink. For this reason, the number of sheets that can be printed with the first ink tanks is fewer than the succeeding ink tanks.
The printing costs described in the brochures or websites are based on the consumption data from not the first ink tank / ink cartridge but the succeeding ink tank / ink cartridge.
To keep printer's performance, Canon printer performs cleaning automatically according to its condition. When the printer performs cleaning, a small amount of ink is consumed. In this case, all colours of ink may be consumed.
The cleaning function helps the printer to suck air bubbles or ink itself from the nozzle and thus prevents print quality degradation or nozzle clogging.
The repairing parts for printers will be available five years after production is discontinued. Depending on your model, we may ask you to replace it with a new one, or one with almost the same performance as a maintenance service. In this case, it may be that you cannot use supplies or accessories for your model or the compatible OS will be changed.
The warranty term for details, contact a Canon-authorized sales representative in the country or region you live in.
To obtain good printing quality, use up ink within six months after opening.
Regarding a solution to a problem caused by using non-genuine ink cartridges (including ones supplemented with non-genuine ink by making a hole in the cartridge or so), a fee will be charged even within the warranty term. Keep this in your mind when you use non-genuine ink.
If you use non-genuine ink cartridges (including ones supplemented with non-genuine ink by making a hole in the cartridge or so), they may have a negative effect on the performance of the printer or the printing quality may be reduced. In addition, though it is a rare case and does not present a safety hazard, it is reported that a print head will become heated or smoke will be emitted from it due to an ingredient not contained in genuine Canon ink. (Note that this does not apply to all non-genuine ink.)
The following functions are available only on printers that use genuine Canon ink for all colours and support these functions. For supported functions, see the product specifications section for each model.
• Printing CREATIVE PARK PREMIUM content via My Image Garden, Easy-PhotoPrint+, or PIXMA Cloud Link
• Using the following applications via PIXMA Cloud Link
- Scan to E-mail
- Attach to Webmail
- Scan to Office document
- Scan and Remote Print
- Saving scanned images to Dropbox, Google Drive, OneDrive, Evernote, OneNote, Access to SlideShare
A printer with a fax function stores the following fax data in printer's memory:
- Faxes not printed out due to conditions such as ink running out.
- Faxes in the send queue.
If you disconnect the power cord, the date and time settings are reset and faxes stored in the printer's memory will be deleted. Before you disconnect the power cord, confirm that faxes you need to keep have already been printed or sent.
Depending on your terminal, such as a computer or a smartphone, or the operating system of your terminal, such as your computer or smartphone, the information or the message related to the estimated remaining capacity of the maintenance cartridge usage displayed on the screen of your terminal may be different from the information or message displayed on the operation panel of the printer. Also, the message for the estimated remaining capacity of the maintenance cartridge usage may be displayed at a different point in time. Canon recommends that you use the information and massage displayed on the operation panel of the printer as your reference.
Low Cost Cartridges
Affordable ink cartridges for high quality printing.
Compact and Lightweight
Allow the printer to easily fit into even the smaller spaces and shelves in a home.
Auto Power ON
Auto Power ON detects a print command and will automatically switch the printer on with a USB connection.
Quiet Mode reduces operation noise to the bare minimum.
